Fire-retardant mechanism:

• When heated: FR35RP breaks down on the surface of the product to produce a thick coating barrier that isolates oxygen, heat and small molecule diffusion during combustion. In addition, decomposition of free radicals and H· and OH· reactions to promote combustion terminate the chain reaction of combustion, and release water and carbon dioxide at the same time, and effectively absorb a large amount of heat generated, play a role in flame suppression, so as to achieve the purpose of efficient flame retardant.

Applications:

• FR35RP is wildly used for mechanical rubber&plastic goods with smooth surface and relatively low specific gravity which are required to meet not only V0 class fire-retardant grade but also Rohs & WEEE, because it does contain polybrominated biphenyl, polybrominated diphenyl ethers, chlorine, fluorine, antimony trioxide and other halogen flame retardants.
• FR35RP is wildly used in rubber goods with fire retardant requirements made of EPDM ,NBR,HCR,NR,SBR,CR IIR,ACM etc.

Key benefits:

• Good dispersibility in the compound.
• Good fluidity of compound with stable size, easy to extrude.
• Low energy consumption during mixing, shorten the curing time.
• Sheet structure with surface treatment.
• High BET and purity with reasonable and small particle distribution
• Excellent chemical stability, Non-toxic and odorless.

Typical properties：

Compound Name	EPDM  70 ° C V0 flame retardant formula
Press cure	180℃*6min	Press cure(compression Set)	180℃*10min
Rheometer 180℃*5min	TS2: 21 sed; TC90:206 sec	ML: 0.39 lbf-in MH:11.9 lbf-in
Raw Material	phr	Condition	Testing Item	Test Data
EPDM 512E	100.00	Physical Property (23±2℃）	Density,g/cm³	1.387
N550	50		Hardness	68
FR35RP	110		M100	1.6
Sanepar916	25		Tensile, Mpa	8
ZNO	8.00		Elongation,  %	601
STA	1.00	Compression Set	%	54.5
D985S	1.00	oxygen index		33
PEG 4000	1.00	Level of flame retardant		UL94V0
DP86B	1.00
S-80	1.28
AG60	5.00
CaO	8
Total	311.28



Common-usage Level: Its general usage is from 60 to 110phr according to different hardness, physical properties, grade of flame retardant, processing, etc. Generally adding 6-8 Phr will increase one degree of hardness; adding 3-5phr will increase one unit of oxygen index.



Packaging：25 KG/ Bag, 1000 KG/Pallet.



For More Product Information, Please Visit Our Website: www.sanezen.com

Contact: Plant Address: Baishou Road, North District of Xuan Zhou Economic Development Zone, Xuan Cheng City Anhui Province, China. Commercial Address: Room 1606-1608, Boda Commercial Buildings, No. 11 Puhuitang Road Xuhui District, Shanghai, China 200030  Tel: +86 21 6487 9251     Fax: +86 21 5106 2693  E-mail: kevenwang@sanezen.com

Warning to the users:  The information contained in this document is given in good faith based on our current knowledge. It is only an indication and is in no way binding, particularly as regards infringement of or prejudice to third party rights through the use of our products. Sanezen guarantees that its products comply with its sales specifications. This information must on no account be used as a substitute for necessary prior tests which alone can ensure that a product is suitable for given use. Determination of the suitability of product for the uses and applications contemplated by users and others shall be the sole responsibility of users. Users are responsible for ensuring compliance with local legislation and for obtaining the necessary certifications and authorisations. Users are requested to check that they are in possession of the latest version of this document and Sanezen is at their disposal to supply any additional information.
