Silicone Rubber 960U Series
Silicone Rubber 960U Series
Silicone Rubber 960U Series
This series is a premixed compound for electrical insulating silicone rubber vulcanizing under heat after addition of a vulcanizing agent that could be chosen according to processing requirement.
product details
Special properties:
- Good tracking & erosion resistance
- Good hydrophobicity and flame retardancy
- Easy to process and demold, not sticky to rolls
- Good electrical insulation properties
- Superior molding processing performance
- Good mechanical properties
- Suitable dielectric properties
Main applications: Insulating products of different voltage grades. And for all types of electrical insulating equipment for outdoor use, such as composite insulators, surge arresters, bushings, etc.
Characteristics:
Type (according to GB/T 5576-1997)…………………………..VMQ
Natural color……………………………………………………………. Gray
Curing Condition:
After addition of DMDBH 1.2%-1.5% and vulcanization for 5min at 175°C.
Mechanical properties
| Item | Testing Method | Unit | Technical Data |
| SR960U | |||
| Appearance | Visual Observation | Translucent | |
| Hardness | ASTM D2240 | Shore A | 63 |
| Density | ASTM D792 | g/cm3 | 1.53 |
| Mooney Viscosity, ML (1+4) 100°C | GB/T 12828-2006 | 21.5 | |
| Tensile Strength | ASTM D412 | Mpa | 5.4 |
| Elongation | ASTM D412 | % | 278 |
| Tear Strength | ASTM D624 Die B | N/mm | 12 |
| Volume resistivity | IEC 60093 | Ω·cm | 5.3×10 14 |
| Dielectric strength | IEC 60243 | Kv/mm | 21.5 |
| Tracking&Erosion resistance | IEC 60587 | TM1A4.5≤2.5mm | pass |
| Fire resistance | UL-94 | FV-0 | pass |
Packaging：20 kg per cardboard boxes.
Storage and shelf life:
This series may be stored in its original unopened packaging at a temperature below 30°C for up to 10 months as from the date of manufacture. Better use it within three months.
